Description
Better mixing closed control of granules size leads to faster tableting speeds with improved quality & least ejections.
CONSTRUCTION
Mixing bowl with openable lid made out of suitable 4mm thk. SS 316 Quality material and safety interlock. Mixing blade consisting of 3 Nos. full blade specially designed for intense mixing.
Pneumatically operated bottom side discharge valve with safety interlock. Unit is mounted on MS rigid structural stand which is covered from all four sides.
Mixing blade, rotating at 75 / 150 RPM is driven by suitable dual speed Non-FLP Ele motor, 1500 / 3000 RPM, through belt pulley assembly and worm – worm wheel reduction gear box.
Mixing blade, rotating at 75 / 150 RPM is driven by suitable dual speed Non-FLP Ele motor, 1500 / 3000 RPM, through belt pulley assembly and worm – worm wheel reduction gear box.
Granulating blade rotating at 1500 / 3000 RPM, directly driven by suitable dual speed flange mounted 380 V / 415 V, 3 phase Non FLP Electric motor.
Electrical control panel mounted aside the machine platform itself for easy operability panel consisting of switch gears, fuses relays, motors, starters, indicating lamps, push buttons, control for discharge valve, ammeter for main motor and granulating motors, pneumatic solenoid valve and pressure switch for pneumatic seal.
All these are contained in S.S.304 quality panel. Pneumatic circuit would of a pressure line of 4 to 5 kg/cm²with filter cum re gulator.
Removable Mat finished S.S.304 covers with louvers for ventilation are provided on all sides of the machine base frame to impart GMP Norms. All material contact surfaces are mirror polished and material non-contact surfaces are mat polished. All MS parts of the machine are ground smooth, red oxide painted and cladded with S.S.304 sheet metal in order to meet GMP standard. Machine can be cleaned thoroughly by water. Teflon seal and air seal are provided for main blade where as gland packing and air seal are provided for granulating blade.
